Product Attribute Attribute Value Select Attribute
Manufacturer: onsemi
Product Category: MOSFETs
RoHS:  Yes
REACH - SVHC:
Technology: Si
Mounting Style: Through Hole
Package/Case: TO-3PN-3
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 900 V
Id - Continuous Drain Current: 9 A
Rds On - Drain-Source Resistance: 1.4 Ohms
Vgs - Gate-Source Voltage: - 30 V, 30 V
Vgs th - Gate-Source Threshold Voltage: 3 V
Qg - Gate Charge: 58 nC
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
Pd - Power Dissipation: 280 W
Channel Mode: Enhancement
Tradename: QFET
Packaging: Tube
Brand: onsemi
Configuration: Single
Country of Assembly: Not Available
Country of Diffusion: Not Available
Country of Origin: CN
Fall Time: 75 ns
Product Type: MOSFETs
Rise Time: 120 ns
Series: FQA9N90C_F109
450
Subcategory: Transistors
Transistor Type: 1 N-Channel
Typical Turn-Off Delay Time: 100 ns
Typical Turn-On Delay Time: 50 ns
Part # Aliases: FQA9N90C_F109
Unit Weight: 4.600 g
